Lenovo ThinkBook 14 G8 Ultra 5 135H/16GB/512GB SSD/14.0″/Win11Home

Brand
Lenovo

Description
TB14 G8 U5-135H 16G SSD512G W11H 4C


Part Number
21SJ00FCTH

Processor
Intel Core™ Ultra 5 135H, 14C (4P + 8E + 2LPE) / 18T, Max Turbo up to 4.6GHz, 18MB Intel® Smart Cache

AI PC Category
AI PC

NPU
Integrated Intel® AI Boost, up to 11 TOPS

Graphics
Integrated Intel® Arc™ Graphics Functions as Intel® Graphics

Chipset
Intel® SoC Platform

Memory
1x 16GB SODIMM DDR5-5600

Memory Slots
Two DDR5 SODIMM slots, dual-channel capable

Max Memory
Up to 64GB DDR5-5600

Storage
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®

Storage Slot
Two M.2 2280 PCIe® 4.0 x4 slots

Max Storage Support
Up to two drives, 2x M.2 SSD
• M.2 2280 SSD up to 2TB each

Card Reader
SD Card Reader

Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec

Speakers
Stereo speakers, 2W x2, Dolby Audio™

Microphone
2x, Array

Camera
FHD 1080p with Privacy Shutter

Battery
60Wh

Power Adapter
65W USB-C® (3-pin)

Special Features
Modern Standby

Display
14" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC, 60Hz

Touchscreen
None

Screen-to-Body Ratio
90%

Color Calibration
No Color Calibration

Pen
Pen Not Supported

Keyboard
Non-backlit, Thai

Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)

Dimensions (WxDxH)
313.5 x 224 x 17.5 mm (12.34 x 8.82 x 0.69 inches)

Weight
Starting at 1.36 kg (2.99 lbs)

Case Color
Arctic Grey

Case Material
Aluminium (Top), PC-ABS (Bottom)

Surface Treatment
Anodizing Sandblasting (Top), Texture (Bottom)

Operating System
Windows® 11 Home Single Language, English (US) / English (UK)

Bundled Software
Office Trial

WLAN + Bluetooth
Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3

WWAN
WWAN Not Supported

Ethernet
100/1000M (RJ-45)

Standard Ports
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On, 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 45-65W and DisplayPort™ 1.4, 1x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 45-65W and DisplayPort™ 2.1, 1x HDMI® 2.1, up to 4K/60Hz, 1x Headphone / microphone combo jack (3.5mm), 1x Ethernet (RJ-45), 1x SD card reader

Docking
Various docking solutions supported via Thunderbolt™ / USB-C®.
For more compatible docking solutions, please visit Docking for ThinkBook® 14 G8 IAL

Security Chip
Firmware TPM 2.0 Enabled

Physical Locks
Kensington Nano Security Slot™, 2.5 x 6 mm

Fingerprint Reader
Touch Style, Match-on-Chip, Integrated in Power Button

Other Security
Camera privacy shutter

System Management
Non-vPro®

Warranty
1Y Onsite upgrade from 1Y Courier/Carry-in

*ผิด ตก ยกเว้น Errors and omissions excepted (E&OE)*
