Huawei Indoor AP371 Access Point

Brand
 Huawei

Description
 Huawei Indoor AP371 Access Point

SKU
 AP371

Wi-Fi standard
 2.4 GHz: 802.11b/g/n/ax/be 5 GHz:802.11a/n/ac/ac Wave 2/ax/be

Installation Type
 Wall,Ceiling (Solid Wall/Gypsum Board/Spring Tee/Flat-Edge T-Rail/Channel Rail/Beam/Threaded Rod)

Optimal Signal Distance (m)
 18

Device Rate
 3.57 Gbps

Max Number of Access Users
 256

Recommended Number of Access Users
 150

Maximum number of physical ports on the entire device
 2.5GE (RJ45) x 1, 100M/1000M/2500 Mbit/s auto-sensing

Radio number
 2

Maximum channel bandwidth [MHz]
 Radio 0 (2.4 GHz): 40 MHz Radio 1 (5 GHz): 160 MHz

Maximum transmit power
 2.4 GHz: 20 dBm/chain 23 dBm (combined power) 5 GHz: 20 dBm/chain 23 dBm (combined power)

MIMO spatial streams
 Radio 0 (2.4 GHz): 2x2 Radio 1 (5 GHz): 2x2

Maximum power consumption [W]
 13.3 (excluding USB)

Input voltage range [V]
 DC: 12 V ± 10% PoE: 802.3at/af

Radio interface
 Built-in smart antennas

Antenna gain
 2.4 GHz: 4 dBi/chain (peak gain) 1 dBi (combined gain) 5 GHz: 5 dBi/chain (peak gain) 3 dBi (combined gain)

Operating frequency band
 2.4GHz,5GHz

Dimensions
 without packaging (H x W x D) [mm(in.)]
 Diameter x depth: 180 mm x 35 mm (7.09 in. x 1.38 in.)

 with packaging (H x W x D) [mm(in.)]
 61 mm x 231 mm x 203 mm (2.40 in. x 9.09 in. x 7.99 in.)

Weight
 without packaging [kg(lb)]
 0.47 kg (1.04 lb)

 with packaging [kg(lb)]
 0.69 kg (1.52 lb)

Warranty
 3 Years
