Huawei Wall plate AP162E Access Point

Brand
 Huawei

Description
 Huawei Wall plate AP162E Access Point

SKU
 AP162E

Wi-Fi standard
 2.4 GHz: 802.11b/g/n/ax 5 GHz: 802.11a/n/ac/ac Wave 2/ax

Installation Type
 Junction Box (86 mm)

Optimal Signal Distance (m)
 15

Device Rate
 2.975 Gbps

Max Number of Access Users
 128

Recommended Number of Access Users
 48

Maximum number of physical ports on the entire device
 GE (RJ45) x 2, 10M/100M/1000M auto-sensing

Radio number
 2

Maximum channel bandwidth [MHz]
 Radio 0 (2.4 GHz): 40 MHz Radio 1 (5 GHz): 160 MHz

Maximum transmit power
 2.4 GHz: 17 dBm/chain 20 dBm (combined power) 5 GHz: 17 dBm/chain 20 dBm (combined power)

MIMO spatial streams
 Radio 0 (2.4 GHz): 2x2 Radio 1 (5 GHz): 2x2

Maximum power consumption [W]
 9.1

Input voltage range [V]
 PoE: 802.3af

Radio interface
 Built-in smart antennas

Antenna gain
 2.4 GHz: 3 dBi/chain (peak value) 3 dBi (combined gain) 5 GHz: 2 dBi/chain (peak value) 1 dBi (combined gain)

Operating frequency band
 2.4GHz,5GHz

Dimensions
 without packaging (H x W x D) [mm(in.)]
 86 mm x 86 mm x 42.5 mm (3.39 in. x 3.39 in. x 1.67 in.)

 with packaging (H x W x D) [mm(in.)]
 98 mm x 117 mm x 73 mm (3.86 in. x 4.61 in. x 2.87 in.)

Weight
 without packaging [kg(lb)]
 0.14 kg (0.31 lb)

 with packaging [kg(lb)]
 0.24 kg (0.53 lb)

Warranty
 3 Years
