Aruba R9B28A, Instant On AP25 (RW) Wi-Fi 6, 802.11ax, 4x4 Access Point

Brand
 Aruba

Description
 Aruba R9B28A, Instant On AP25 (RW) Wi-Fi 6, 802.11ax, 4x4 Access Point

SKU
 R9B28A

Radios
 Dual radio for simultaneous dual-band operation
 5 GHz 802.11ax 4x4 MIMO for up to 4.8 Gbps wireless data rate, with Multi User MIMO support (Wi-Fi 6)
 2.4 GHz 802.11ax 2x2 MIMO for up to 574 Mbps wireless data rate (Wi-Fi 6)

Maximum (aggregate, conducted total) transmit power (limited by local regulatory requirements)
 5GHz band: +24dBm (+18dBm perchain, 6dB MIMO gain)
 2.4Ghz band: +21dBm (+18dBm perchain, 3dB MIMO gain)

Interface
 Uplink 2.5 Gigabit Ethernet port, with PoE-in support (802.3at)
 DC power connector (12V) Bluetooth Low Energy (BLE) radio LED status indicators (2) Reset/LED control button Kensington security slot

Antenna
 Down-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 3.77 dBi in 2.4GHz and 4x4 MIMO with peak antenna gain of
 4.55 dBi in 5GHz (of the effective, combined pattern for both antennas in each band)

Environmental & reliability
 Operating temperature: 0° C to +40° C (+32° F to +104° F)
 MTBF: 670khrs (76yrs) at +25° C

Mounting
 The access point ships with a white mount clip that can attach to both walls and ceilings
 Mounts that match the design of the APs can be purchased separately

Management options
 Instant On mobile application (Android & iOS)
 Cloud Portal: Portal.ArubaInstantOn.com

Industry certifications
 EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments)
 Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3

Power Consumption
 Power over Ethernet (POE): 802.3at (class 4)

 Max power consumption (worst-case): 20.1W (PoE), 15.9W (DC)

 DC power (12V)

 Note: Power sources are sold separately unless you purchase the bundle SKU which comes with power options.

Dimension
 200mm x 200mm x 45mm, excluding mount accessories

Weight
 775g

Warranty
 2 Years

Datasheet : Aruba Instant On AP25

*ผิด ตก ยกเว้น Errors and omissions excepted (E&OE)*
