D-Link DMS-1100-10TP, 10-port 2.5G Smart Managed PoE (240W) Switch with 2-port 10G Uplinks

Brand
 D-Link

Description
 D-Link DMS-1100-10TP, 10-port 2.5G Smart Managed PoE (240W) Switch with 2-port 10G Uplinks

SKU
 DMS-1100-10TP

Interfaces
 8x 100/1000/2.5GBASE-T PoE ports
 2x SFP+ ports

Port Standards
 IEEE 802.3u 100BASE-TX
 IEEE 802.3ab 1000BASE-T
 IEEE 802.3z 1000BASE-X
 IEEE 802.3bz 2.5GBASE-T
 IEEE 802.3ae 10G over fiber
 IEEE 802.3az
 IEEE 802.3af/at (DMS-1100-10TP)

Console Port
 RJ-45 port for out-of-band CLI management

Network Cables for 2.5GBASE-T
 Cat 5e (100 m max)

Media Interface Exchange
 Auto MDI/MDIX adjustment for all twisted-pair ports

Switching Capacity
 80 Gbps

Transmission Method
 Store-and-Forward

MAC Address Table
 Up to 16 ,000 entries per device

PoE
 PoE Standard : IEEE 802.3af/at
 PoE Ports : Ports 1 to 8
 PoE Power Budget : 240 W

LEDs
 Link/Activity/Speed (Per 2.5GBASE-T port)
 Link/Activity/Speed (Per 10G SFP+ port)
 POWER, FAN error, PoE status

Operating Temperature
 -5 to 50 °C (23 to 122 °F)

Certifications
 CE, FCC, C-Tick, VCCI, BSMI, CCC

Safety
 cUL, CB, CE, CCC, BSMI

Power Input
 100 to 240 VAC

Max Power Consumption
 PoE on: 293.4 W
 PoE off: 38.1 W

Standby Power Consumption
 27.3 W

Humidity
 0% to 95% non-condensing

MTBF
 676,329 hours

Dimensions (L x W x H)
 440 x 250 x 44 mm (17.32 x 9.84 x 1.73 in)

Weight
 3.43 kg (7.56 lbs)

Warranty
 5 Years

Datasheet : DMS-1100 Series
